Name: 304 Stainless Steel Welded Razor Wire Mesh Anti Climbing Prison Fencing
Brand: Taiye
SKU: 122

304 Stainless Steel Welded Razor Wire Mesh Anti Climbing Prison Fencing

Product Details:

Place of Origin:	ANPING CHINA
Brand Name:	Taiye
Certification:	ISO9000 ISO140001
Model Number:	122

Payment & Shipping Terms:

Minimum Order Quantity:	1tons
Price:	To be negotiated
Packaging Details:	1. Packed on palllet 2. by rolls
Delivery Time:	3-8 days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	20tons per day

Contact Now

Detailed Product Description

Material:

Galvanized( Electric Galvanized, Hot Dipped Galvanized, High Galvanized) Epoxy, Electrophoretic, Stainless Steel(304, 316, 316L)

Razor Fence Woven Type:

Welded

Package:

By Roll

Hole Shape:

Square And Diamond

High Light:

welded wire mesh fence

galvanized welded wire mesh

High Quality 304 Stainless Steel Welded Razor Barbed Wire Mesh Prison Fence

Welded Razor Wire Description

Welded razor mesh is a multi-functional, high security mesh fencing made of straight-blade netting welded together, packaging into a roll form for transport. Razor wire mesh is used in operations to pave the field after the installation of a blade barrier. This product can protect you and your property, and ensures the safety of the protective barriers.

Welded razor wire mesh is also known as straight-line razor wire, is by the blade thorn rope straight welded together, is modified according to the welded wire mesh, main function is to guard against theft, climbing and isolation.

» Material:

1. hot galvanized sheet and stainless steel sheet 304 316 and so on
2. Galvanized wire(Electro galvanized and hot dipped galvanized)

» Specifications

Welded razor wire fence Hole Type:

1> Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm.

2> Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.

Gauge diameter	Hole shape	Mesh width	Suited blade specifications
100mm×100mm	Square hole,diamond	1.2m ~ 2.4m	BTO-10.12.18.22.28.30, CBT-60.65
100mm×150mm	Square hole,diamond	1.2m ~ 2.4m	BTO-10.12.18.22.28.30, CBT-60.65
100mm×200mm	Square hole,diamond	1.2m ~ 2.4m	BTO-10.12.18.22.28.30, CBT-60.65
150mm×300mm	Square hole,diamond	1.2m ~ 2.4m	BTO-10.12.18.22.28.30, CBT-60.65
other nets hole can according to customers' special needs)

Welded Razor Wire Mesh Surface Treatment:
Galvanized Coating:50-60g/m2 , 80-100g/m2 , 200-250g/m2
PVC Coated Color: green,red,white etc.

Welded Razor Mesh Fence is a new form of razor barbed wire mesh for security. It with practicality blade and the feature looks very beautiful. It can be used for guard net of fence, doors and windows and also can be used in military.

The specification can be designed as the customers’ need.

Welded Razor Wire Mesh Surface Package:

Welded Razor Wire Mesh packed by rolls or pcs sheet on pallet.

Type	Thickness of Sheet	Wire Diameter	Height	Length	Mesh Size
Diamond Hole Razor Mesh	0.5mm±0.05mm	2.5mm±0.1mm	1.0m-2.4m	2.0m-10.0m	75mmx150mm 100mmx200mm 150mmx300mm
Square Hole Razor Mesh					150mmx150mm 200mmx200mm 300mmx300mm
Special Specification can be produced according to your request

Reference Number	Blade Style	Thickness	Wire Dia	Barb Length	Barb Width	Barb spacing
BTO-10		0.5±0.05	2.5±0.1	10±1	13±1	26±1
BTO-12		0.5±0.05	2.5±0.1	12±1	15±1	26±1
BTO-18		0.5±0.05	2.5±0.1	18±1	15±1	33±1
BTO-22		0.5±0.05	2.5±0.1	22±1	15±1	34±1
BTO-28		0.5±0.05	2.5	28	15	45±1
BTO-30		0.5±0.05	2.5	30	18	45±1
CBT-60		0.5±0.05	2.5±0.1	60±2	32±1	100±2
CBT-65		0.5±0.05	2.5±0.1	65±2	21±1	100±2
Barbed Tape Concertina (CBT);Barbed Tape Obstacle (BTO) Standard materials are either galvanized or stainless steel. Standard packages products are shown in the tables above, special specifications available on request.
