Name: Iron Wire Galvanized Pyramid Flat Razor Wire BTO - 22 3D In Security Fence
Brand: Taiye
SKU: 3D RW-01
Rating: 5 (129 reviews)

Home Products Stainless Steel Razor Wire

Iron Wire Galvanized Pyramid Flat Razor Wire BTO - 22 3D In Security Fence

Product Details:

Place of Origin:	Anping,China
Brand Name:	Taiye
Certification:	ISO9001 ISO10001
Model Number:	3D RW-01

Payment & Shipping Terms:

Minimum Order Quantity:	0.5 ton
Price:	According to the material
Packaging Details:	1.woven bag 2.wooden case 3.wooden pallet
Delivery Time:	3 days - 15 days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	16 tons per day

Contact Now

Detailed Product Description

Material:	Iron Wire	Surface Treatment:	Zine Coated
Razor Type:	BTO 22	Razor Length:	22 Mm
Razor Width:	15 Mm	Usage:	Protection,prevent
High Light:	razor wire mesh fencing , razor barbed tape

Galvanized Pyramid Razor Wire BTO-22 3D Razor Barbed Wire in Security Fence

1.Pyramid Razor Wire Description

Pyramid type razor wire t consists of three sets or 6 sets of razor ropes. Generally, the upper razor wire has a diameter of 98 cm, and the lower two razor wire diameters are 73 cm. There are various types of blade barbed wire, and the type of use can be determined according to requirements, generally BTO-22. Each set of pyramid blade barbed wire ends will have a hexagonal tripod for fixing, which is convenient for the trailer to stretch.
It is mainly used in the military essentials, quickly and quickly split the base, playing a strong defense role. Pyramid-type lancet is favored by its defense boundary and prison defense because of its convenient use and strong lethality.

2.Pyramid Razor Wire Detail

Razor Wire BTO-22
Thickness	0.5 ± 0.05
Wire Diameter	2.5 ± 0.1
Barb Length	22 ± 1
Barb Width	15 ± 1
Barb Distance	34 ± 1

Outside Diameter	No.of Loops	Standard Length per Coil	Type	Notes
450mm	56	8-9m(3 clips)	BTO-22	Cross type
500mm	56	9-10m(3 clips)	BTO-22	Cross type
600mm	56	10-11m(3 clips)	BTO-22	Cross type
600mm	56	8-10m(5 clips)	BTO-22	Cross type
700mm	56	10-12m(5 clips)	BTO-22	Cross type
800mm	56	11-13m(5 clips)	BTO-22	Cross type
900mm	56	12-14m(5 clips)	BTO-22	Cross type
960mm	56	13-15m(5 clips)	BTO-22	Cross type
980mm	56	14-16m(5 clips)	BTO-22	Cross type

3.Pyramid Razor Wire Application

Pyramid razor wire fence is also widely used in security fence system.

High defence metal fence, low cost structure, perfect protection of prison and key project.
The pyramid razor wire fence is usually made up of several coils razor wire.
